XTremo - Shape Expert

Shape

  • PENTAGONE

  • HEXAGONE

  • ASSCHER

  • BALLON

  • BHALA

  • CIRCLE

  • EMRALD

  • FIVE STAR

  • FOUR STAR

  • DIAMOND

  • HALF CIRCLE

  • HEART

  • INVERT PIE

  • MARQUISE

  • OVAL

  • PEAR

  • PRINCESS

  • SQUARE CUT

  • SQUARE ROUND

  • BAGUETTE

  • TRAPEZE

  • TRIANGLE

  • TRILLION

  • BULLET

  • CUSTOM SHAPE

  • 1
    Customize shape for diamond bruting process.
  • 2
    Consistent Results and Reliability.
  • 3
    Exceptional Beam Quality gives lowest breakages.
  • 4
    Sealed Resonator.
  • 5
    Best model in Performance with attractive & sleek design in industry.
  • 6
    Robust and sturdy structure for lowest vibration, minimum maintenance and high quality output.
  • 7
    Industry proven Components for long terms stability.
  • 8
    Polarization control allows to cut in any direction.
  • Laser
    : Nd:YAG DPSSL
  • Spatial Mode
    : TEM00
  • Wavelength
    : 1064 nm
  • Polarization
    : Linear
  • Beam Roundness
    : >90%
  • Average Power
    : >16 W
  • Repetition Rate
    : 6-12 KHz
  • Cooling Water
    : Steam Distilled
  • Axis Travel
    : 130 mm x 130 mm x 70 mm
  • Resolution
    : 2 Micron
  • Accuracy
    : 2 Micron / 25 mm
  • Repeatability
    : 2 Micron /25 mm Bidirectional
  • Drive
    : AC Servo & Stepper
  • Power Requirement
    : 220 VAC + 10%, 1 Phase, 50 Hz
  • Power Consumption
    : < 2.5 KVA
  • Room Temperature
    : 240 C - 260 C
  • Length x Width x Height
    : 1500mm x 650mm x 1500mm
  • Weight
    : 370 Kg
